CT-TPR-13-1-super - SECOND GENERATION TPR COATED HEAVY DUTY FABRIC
FEATURES:
- Temperature resistant
- Abrasion resistant
- Tear resistant, high tensile, EPDM rubber coated fabric
- Chemical and moisture resistant
- Hot air and wedge weldable
APPLICATION:
- Custom slit product: Possible use - flexible duct production for permanent and temporary ventilation.
- Full size rolls: Possible use- weldable water proof rubber fabric membrane in roofing and construction applications.
| PROPERTIES | Values (Metric) | Values (English) |
|---|---|---|
| Construction |
Base fabric: high tensile polyester |
Base fabric: high tensile polyester Both sides TPR coated |
| Thickness | 0.45 mm | 17.5 mil |
| Total area weight | 426 g/m2 | 12.5 oz/yard2 |
| Tensile (breaking) strength (MD) | 1202 N/50mm | 135 lbs/inch |
| Tensile (breaking) strength (TD) | 933 N/50mm | 105 lbs/inch |
| Tear strength (MD) | 88 N | 20 lbs |
| Tear strength (TD) | 79 N | 18 lbs |
| Adhesion Strength | 80-89 N/50mm | 18-20 lbs/2in |
| Abrasion Resistance | 1500 cycles / 3.75% weight loss | 1500 cycles / 3.75% weight loss |
| Temperature resistance, 30min test | 170 oC | 340 oF |
| Roll width | Custom: 37-200mm Jumbo roll: 1.42m |
Custom: 1.5-8" Jumbo roll: 56" |
| Roll length | 200m custom roll length is available |
219 yards custom roll length is available |
| Color | Black (standard) custom colors are available |
|
| Optional treatments | Anti static, flame retardant, UV resistant treatments are available by special request | |
